Arc Stud Welding Machine

Applications:

Construction, Automobile, Shipbuilding, Pressure Vessel, Petrochemical, Power Generation Equipment, etc.

Standard : GB CCC CE

Product details

Arc Stud Welding Machine
RSN-1000 RSN-1600 RSN-2500
Product features:

1. It is digital, hard switch and inverter technology, small size, light weight and easy to move;

2. Noil has automatic compensation function of voltage fluctuation of power grid;

3. The welding current and time are controlled by the single chip, the welding heat is accurate and the qualification rate is high;

4. The gun function is used to inspect the welding before welding;

5. It has automatic manual selection, suitable for special occasions such as multilayer penetration welding;

6.The digital display, welding current, welding time;

7. It is mainly used for welding of bolts of carbon steel and stainless steel;

8. It is widely used in steel structures, Bridges, locomotives, shipbuilding, boilers and industrial furnaces.

Product Type	RSN-1000	RSN-1600	RSN-2500
Input power	AC380V±10%/50Hz
Rated input current	95A	112A	162.5A
Rated power	52KW	69KW	94KW
Rated welding voltage	32V	32V	32V
Power(When the maximum output)	70%	74%	80%
Power factor(When the maximum output)	0.95	0.95	0.95
Adjust the range of welding current	100-1000A	100-1600A	100-2500A
Weldable pin diameter	φ6-16	φ6-19	φ6-25
Welding time	0.01-9.99s	0.01-9.99s	0.01-9.99s
Weldable pin length	≤400mm	≤400mm	≤400mm
Power weight	90Kg	95Kg	96.9Kg
Insulation class	IP21S	IP21S	IP21S
Dimensions	750X315X830mm	760X335X870mm	780X355X870mm
